Fetch hierarchical data records from Airtable with multi-level relationships

Airtable Hierarchical Record Fetcher Description This n8n workflow retrieves an Airtable record along with its related child records in a hierarchical structure. It can fetch up to 3 levels of linked records and assembles them into a comprehensive JSON object, making it ideal for complex data relationships and nested record structures. Features - Multi-level Record Fetching: Retrieves parent record, linked child records (level 2), and optionally grandchild records (level 3) - API Call Optimization: Uses Airtable's filterByFormula to minimize API calls by fetching multiple related records in single requests - Selective Level 3 Fetching: Only fetches level 3 records for specified linked fields to optimize performance - Rich Text Processing: Converts Airtable's pseudo-markdown rich text fields to HTML format - Hierarchical JSON Output: Organizes all data in a structured, nested JSON format - Flexible Configuration: Customizable depth and field selection per execution Input Parameters The workflow accepts a JSON array with the following structure: Parameter Details | Parameter | Type | Required | Description | |-----------|------|----------|-------------| | baseid | string | Yes | Airtable base identifier | | tableid | string | Yes | Airtable table identifier for the main record | | recordid | string | Yes | Airtable record identifier to fetch | | level3 | array | No | Array of field IDs from level 2 records for which to fetch level 3 children | | tohtml | boolean | No | Convert rich text fields from pseudo-markdown to HTML (default: false). This requires marked npm package. | Output Structure The workflow returns a hierarchical JSON object with the following structure:
